Properties
product.use.formulating.properties.Title |
|
|---|---|
| Cure Characteristics | Heat Cure greater than 100C |
| Number of Parts | One Part |
typical.properties.Title |
|
|---|---|
| Color | Gray |
| Color - Part A | Gray |
| Color as dispensed | Gray |
| Cure time (to > 90% final adhesion) | 30 minutes @ 105°C, 5 minutes @ 125°C |
| Dielectric Constant at 100 Hz | 3.2 |
| Dielectric Constant at 100 kHz | 3.1 |
| Dielectric Constant at 1MHz | 3.1 |
| Dielectric Strength | 15.7 kV/mm |
| Dissipation Factor at 100 Hz | 0.001 |
| Durometer - Shore A | 20 |
| Elongation | 600 % |
| Number of Parts | One Part |
| Product Type | Adhesive / Sealant |
| Specific Gravity | 1.15 g/mL |
| Tensile Modulus (tensile strength at 100% elongation) | 0.34 MPa |
| Tensile Strength in MPa | 2.93 MPa |
| Thixotropic | 3 |
| Unprimed Adhesion - Lap Shear | 1.89 MPa |
| Viscosity as dispensed at 25°C (2 rpm, HAT 7) | 650000 cP |
| Viscosity as dispensed at 25°C (20 rpm, HAT 7) | 250000 cP |
| Volume Resistivity | 1.1E+13 Ω・cm |
