DOWSIL™ VE-8001 Flexible Silicone Adhesive

Two-part elastic hinge adhesive solution for flexible OLED display applications in foldable and rollable consumer devices.

Uses:

  • Flexible OLED displays
  • Foldable and rollable consumer devices

Benefits:

  • Stable mechanical properties after the dynamic and static folding test
  • Appropriate tensile strength and elongation for small folding radius
  • Low temperature cure (80°C for 60 minutes at 300 um thickness)
  • Long working time at room temperature (12 hours)

Properties

These values are not intended for use in preparing specifications.

Typical Properties

  • Color Yes No Black
  • Cure Condition Yes No 80°C for 1 hour at 0.3 mmT
  • Elongation Yes No 40 %
  • Lap Shear Strength Yes No >850 psi & >5.86MPa (SUS to SUS 25mm x 10mm x 0.5mmT)
  • Linear CTE Yes No 250 ppm/°C
  • Mixing Ratio Yes No 1:1 wt%
  • Pot Life Yes No 720 Minutes
  • Specific Gravity Yes No 1.01 g/cm³
  • Tensile Strength (SI) Yes No 12 MPa
  • Viscosity Yes No 10,000 ~ 15,000 cP

Elastic silicone adhesive for foldable electronic display devices

Foldable and rollable electronics displays are expanding our concept of consumer electronics, such as smart phones and tablets. This technology requires materials that not only enable elasticity required for folding or rolling flexible displays but materials that also maintain stable mechanical properties after folding, materials like DOWSIL™ VE-8001 Flexible Silicone Adhesive.

A two-part elastic hinge adhesive solution for flexible OLED display applications in foldable and rollable consumer devices, DOWSIL™ VE-8001 Flexible Silicone Adhesive provides the appropriate tensile strength and elongation for the small folding radius of electronics displays. This product is based on heat cure (80°C for 30 minutes at 300 um thickness), which provides stable mechanical properties after dynamic and static fold testing for foldable and roll-able display devices. With these performance benefits, which of your ideas for foldable and rollable electronics might be enabled by DOWSIL™ VE-8001 Flexible Silicone Adhesive?

A flexible solution for foldable displays

DOWSIL™ VE-8001 is a two-part elastic hinge adhesive for foldable and rollable consumer devices.
